Fast and high quality true-color bitmap rotation function

The code is Pentium MMX optimized implementation of bitmap rotation by means of 3 shears.

## Sources and Motivation

This popular algorithm was proposed by Alan Paeth (Alan Paeth, "A Fast Algorithm for General Raster Rotation," Graphics Interface '86, pp. 77-81, May 1986.) For online explanation see Tobin Fricke notes. The software implementation I came across on codeproject.com belongs to Eran Yariv.

This implementation

• while providing good quality is rather slow ("Code is optimized for image quality, not speed.")
• while claims to support "generic bitmap structures", always uses COLORREF as underlying pixel representation, which seriously limits flexibility.

## Benefits

My implementation is about 6 times faster (tested on Athlon 1.4) and more flexible.

Speed is achived by:

• using byte weight factor instead of double for linear interpolation;
• implementing internal shear loop in assembler using MMX instructions;
• eliminating virtual functions for individual pixel access and using static polimorfism instead.

Flexibility is achived by using design policies, inspired by Andrei Alexandrescu.

## Interface

Class ImageRotate is parameterized by callback type, Allocator and Alignment policies.

``` template< typename ProgressAnbAbortCallBack = CallbackFn, class AllocatorPolicy = AllocatePolicyStdNew, class AlignmentPolicy = AlignmentPolicyBmp > class ImageRotate; ```

Source and destination images are described by

 class ImageRotate::Img Pixel * pixel struct { unsigned __int8 c[4]; } unsigned width in Pixels unsigned height in Pixels unsigned width_pad in bytes

Public interface of ImageRotate consists from single function

``` static Img AllocAndRotate ( const Img &src, Pixel clrBack, // Background color double angle, // Rotation angle ProgressAnbAbortCallBack *cb = 0); ```

static Img AllocAndRotate ( const Img &src, Pixel clrBack, // Background color double angle, // Rotation angle ProgressAnbAbortCallBack *cb = 0); Callback type should support

``` bool operator() (double) ```

bool operator() (double) and may not raise exceptions. It could be function pointer (default) or functor class (e.g. Loki::Functor). Function gets double value of progress percentage in 0-100 range and returns false to abort calculation or true otherwise.

AllocatorPolicy should provide 2 methods w/o exceptions raising:

``` void* allocate(size_t); void free(void *t); ```

void* allocate(size_t); void free(void *t); It could be "C" malloc/free (default) or custom memory manager.

AlignmentPolicy should provide 1 method w/o exception raising:

``` unsigned aligned_width(unsigned width); ```

unsigned aligned_width(unsigned width); By default, it implements Windows BMP 4 byte alignment.

Source and rotated images are kept in ImageRotate::Img classes. Client is responsible to delete returned rotated image pixel array, using image.Free();

 References 1 Alan Paeth A Fast Algorithm for General Raster Rotation, Graphics Interface '86, pp. 77-81, May 1986. 2 Tobin Fricke Rotation by Shearing 3 Eran Yariv High quality image rotation (rotate by shear) 4 Intel Corporation Using MMX™ Instructions to Implement Alpha Blending 5 Todd Veldhuizen Techniques for Scientific C++ 6 Andrei Alexandrescu Modern C++ Design 7 SourceFORGE.net Project: Loki
